Condition

New


Sales Dept., 1-866-458-5915

CraneWorks, Inc. Make Offer Get Financing

Features

Rated Capacity Limiter System: RCL displays information on length and angle of boom, working radius, rated load and total weight being lifted. Standard Work Area Definition System (WADS) allows operator to pre-select and define safe working areas. Internal anti-two block wiring.
Boom Elevation: One (1) double acting hydraulic lift cylinder with integral holding valve. (-10° to 80°)
Crane Cab: Deluxe operator cab equipped with diesel cab heater, front and rooftop wipers, swinging door, fan, horn, control console with single axis joysticks in arm rests, hand/foot electronic throttle controls, engine start/stop switch, and LMI display.
Swing: 360° continuous rotation with "Glide Swing" and manual foot brake in cab. Adjustable swing speed.
Hydraulic System: Single, variable displacement, pressure compensated control valves, hydraulic reservoir capacity is 99 gallons (374,75 L), sight gauge, 10-micron filter on the return line, and suction line gate valve. Hydraulic oil cooler is standard.
Hoist: High performance planetary two-speed winch. Bare drum pull 12,000 lbs. (5488,4 kg) low speed. Electronic drum rotation indicator (DRI), last layer indicator (LLI).
Wire Rope: 375 ft (99,1 m) of 5/8" (16 mm) rotation resistant wire rope (5:1 safety factor). Single line pull 9,000 lbs. (4082,3 kg) low speed.
Headache Ball: Round downhaul weight with top swivel, 5-ton (4,5 mt) capacity rating.
Outriggers: Two sets of out & down cross frame outriggers with a 24.7' (7,5 m) span which can be positioned at mid span 17' (5,2 m) with manual locks. Outriggers are provided with 20" (508 mm)
dia. polymeric removable pads.
Stabilizers: Single front outrigger (SFO) located in the center of the front bumper. Includes "first up" feature.
Torsion Box/Decking: Torsion resisting subbase with rotating turret. Steel full length tread plate decking, provides 8' (2,4 m) bed space between outriggers and front of turret; side and rear access ladders to turret control and rear bumper.
Miscellaneous Standard Equipment: Back up alarm, hour meter in truck cab, outrigger motion alarm, parallel boom rest, rear bumper underride protection, electronic engine throttle (EET), two (2) English owner's manuals (1 paper & 1 USB flash drive) and outrigger monitoring system. PTO and mounting charges not included in standard price.
Standard Paint: Valspar Duraspar® 2K Epoxy Primer and Valspar Duraspar® Ultra 2K Urethane paint -""National Platinum"" color for frame, turret and base boom section; standard ""Black"" for
hydraulic reservoir, SFO, torsion box (frame), inner outriggers, and inner boom sections.

Included options

31.6' -127' (9,6 -38,7 m) five section, full power telescopic boom
30' (9,1 m) fixed boom extension (side fold for stowing)
Two-and three-part reeving, 15-ton (13,6 mt) capacity hook block with one sheave.
Standard Mounting
Hot shift PTO in lieu of air shift PTO
Clockwise rotation pump
Drive line kit
Air conditioning for crane cab. Self-contained modular unit.
Additional outrigger controls located at operator's seat
  • Year: 2023
  • Capacity: 33.00
  • Condition: New
  • Unit #: BM-3938
  • Serial #: 302868
  • Location: Houston Texas USA
